The 2515 sintered bronze plain bearing bushing is a high-performance component designed for use in a wide range of industrial applications. Constructed from sintered bronze, it offers exceptional durability and wear resistance, making it suitable for handling heavy loads and high-speed operations.
The material provides self-lubricating properties, eliminating the need for regular lubrication or maintenance. This feature not only saves time and effort but also reduces operational costs and extends the lifespan of the bearing bushing.
The plain design of the bearing bushing allows for easy installation and replacement, making maintenance a breeze. It also ensures smooth and efficient operation, reducing friction and heat generation during use.
Wh you need to replace worn-out bushings or upgrade your equipment, the 2515 sintered bronze plain bearing bushing is a reliable choice. Its durability and self-lubricating properties make it a cost-effective solution for improving the performance and efficiency of your machinery.
Contact us today to learn more about the 2515 sintered bronze plain bearing bushing and how it can benefit your industrial operations. We offer competitive prices and fast delivery, ensuring you get the best value for your money.
2515 Plain Bearing Bushing
Multi-layer Bearings
Bushing (flange size) from Bronze Bushing. we offers free CAD downloads, short lead times, competitive pricing, and no minimum order quantity.
Plain bearings with resin sliding surface on thin back steel.
Demonstrate superior sliding peformance, wear resistance and thermal conductivity.
Bronze Bushing Drymet LF
Polytetrafluoroethylene plastic multi-layer bearings with back metals
self-lubricating bearings composed of three layers:Polytetrafl uoroethylene plastic layers with fillers, sintered bronze layers, and back metals.
Plain Bearing Bushing Daido Japan, and also from Low Friction Bushing in Germany, material, plain type bush, Steel backed, sintered bronze on the surface, the impregnated, outside of bush will be TIN flash plated. Bushing Sleeve supplier, good plain type bush quality, bushes good price
Self-lubricated plain bearing. Carbon steel shell with sintered bronze layer filled with .
Self-Lubricating Metric Cylindrical Bushing.
25x28x15mm Split Bearing Bush
Self lubricated plain bearings
Carbon steel shell with sintered bronze layer filled with .
- ID – 25mm
- OD – 28mm
- W – 15mm
Gleitbuchse mit
Eigenschaften / Abmessungen in mm
| Bezeichnung | BM 2515, 2515 , PCM .., PAP .. |
| Innendurchmesser | 25,0 |
| Aussendurchmesser | 28,0 |
| Breite | 15,0 |
| Ausführung | Geeignet für Trockenlauf, niedriger Reibwert, geringer Verschleißrate, gute Gleiteigenschaften. Bestehend aus einem Stahlrücken mit aufgesinterter, poröser Bronzeschicht und einer Gleitschicht aus . Die Farbe der Beschichtung kann abweichen. |
| Material | Stahl / Bronze / |
Low Friction Bushing Bush, Plain, 25 x 28 x 15 mm
Plain Low Friction Bushing bushes are plain bearing materials that offer a good performance on both wear and friction over a wide range of temperatures, speeds, and radial and axial loads. Low Friction Bushing Bushes are ideal for construction and agricultural machines or for any other application which requires rotating and sliding motions. Usually Low Friction Bushing bushes operate without lubricants and are resistant to most solvents and industrial liquids.
Specifications for 2515 Split Bush Bearing - Type |
| Reference | MB 2515 |
| Brand | BR |
| Inside Diameter | 25mm |
| Outside Diameter | 28mm |
| Width | 15mm |
| Type | Bearing |
| Weight (KG) | 0.0001 |
Schematic for 2515 Split Bush Bearing - Type |
| B | 15mm |
| D | 28mm |
| d1 | 25mm |
Metal-Polymer Composite Self-lubricating Bushing Material
Steel Back + Porous Bronze Sinter + + Lead
Metal-Polymer Anti-Friction Plain Bearings Characteristics
- self-lubricating bushings offer very good wear and low friction performance over a wide range of loads, speeds and temperatures in dry running conditions
- Bushing material suitable for lubricated applications
- Anti-friction bearing suitable for linear, oscillating and rotating movements
- Approved to standard FAR 25.853 and FAR 25.855 (Federal Aviation Regulations) and ASTM E162:2016 – surface flammability testing for aircraft interior applications
- Tested acc. to ASTM E595/ECSS-Q-ST-70-02C - Outgassing properties of materials used in Spacecraft equipment
- Approved to standard DIN EN 1797 and ISO 21010 (Cryogenic Vessels – Gas/Material Compatibility) for piping, valves, fittings and other components in both gaseous and liquid oxygen for up to maximum temperature of 60°C and oxygen pressure of 25 bars. Contact Viiplus for further details.
AVAILABILITY
Bearing forms available in standard dimensions
- Cylindrical bushes
- Flanged bushes
- Thrust washers
- Flanged washers
- Sliding plates
Metric bearings and imperial bushings made to order: standard bushing forms in special dimensions, half-bushings, special shapes obtained by stamping or deep drawing, customized bushing designs.
